BOYA BY-AM1 Dual Channel Audio Mixer

Save 20%
$136.00 USD $170.00
In stock

Buy a Demo & Save

Buy an Open Box & Save

Interest Free Finance

  • 12 Month Warranty*
  • Click & Collect (Sydney)
  • Same Day Dispatch*
  • Friendly & Expert Advice
  • 100% Australian Stock
  • 7 Day Exchanges*

Designed for people who need a quality recording interface on a budget, the Boya AM-1 Dual-Channel USB 2 Audio Mixer is a dual-channel interface and mixer that provides both 1/4" and XLR connections for a variety of sources, including microphones and line-level instruments. Using this interface, which connects to your computer over USB, you can record audio to your computer, where you can edit or mix it later in your favourite software. This device works for home-recording music and podcasts.

1/4" and XLR Connections
The BY-AM1 provides you with a compact audio recording solution for 1/4" line-in devices, instruments, or XLR microphones, thanks to its combination XLR-1/4" inputs.

High Sample-Rate Support
The device can support a 44.1 to 192 kHz sampling rate, making it suitable for a wide range of recording applications, from CD quality (44.1 kHz) to broadcast standards (48 kHz) to high-res recording (96 kHz).

48V Phantom-Power Support
This interface can provide 48V phantom power for condenser microphones. The power comes from your host device.

Live Monitoring
Thanks to the 1/4" headphone monitor jack and supplied 3.5mm to 1/4" adapter, you can listen to your live input signal with no distracting echo or latency.

Attach to Your Other Accessories
A built-in 1/4" mounting screw on the base can be attached to a tripod and other accessories.

Features

  • For USB Recording at Home
  • Record Line-Level, Instruments, or Mics
  • Combination XLR-1/4" Inputs
  • 1/4" Headphone Output
  • Sample Rate Support up to 192 kHz
  • Supplies 48V Phantom Power
  • Includes USB Cable
  • 1/4" to 3.5mm Adapter for Headphones

Specifications

Frequency Response

20 Hz to 20 kHz (±0.1 dB)

THD

Headphone Output: Line/Monitor Outputs:

Signal to Noise Ratio

Headphone Output: 6 dBu
Line/Monitor Outputs: 10 dBu

Maximum Input Level

Microphone Inputs: 9 dBu (Minimum Gain)
Line Inputs: 15 dBu (Minimum Gain)
Instrument Inputs: 8 dBu (Minimum Gain)

Gain Range

50 dB

Impedance

Line Inputs: 47 Kilohms
Headphone Output: Line/Monitor Outputs: 470 Ohms

Sampling Rate

44.1 to 192 kHz

USB

USB 2.0 (USB Type-B Connector)

Power Requirements

Bus Powered from Host

Phantom Power

48 V from Host

Dimensions

6.3 x 4.1 x 1.6" / 16 x 10.5 x 4.2 cm

Weight

1.4 oz / 408.5 g



*Please note laptop and other accessories not included, shown for illustration purposes only. Please see the 'What's Included' section for full product inclusions.

What's Included

1 x BOYA BY-AM1 Dual Channel Audio Mixer
1 x USB Type-A to USB Type-B Cable (6.6')
1 x 3.5mm to 1/4" Adapter for Headphones
